Solar Motion Wall Light 300lm – PIR, 3 Lighting Modes
Regular price
$57.00 AUD
per
Pack:
Single
A compact round solar wall light with a tilted solar panel on top and a PIR motion sensor under the LED array. Choose dim-plus-motion, off-plus-motion or constant light; a 1200mAh battery gives 3–4 days of use after a full char...
- 100% Green Energy
- Built to Last
- Easy Installation
| Specification | Value |
|---|---|
| Model Number | SWL-01B |
| Product name | Portable Multi-Functional Solar LED Wall Light |
| Power Supply | Solar / Battery |
| Solar panel | High Efficiency Poly-Si (Lifespan >5 years) |
| Battery | Li-ion Battery |
| Solar charging time | 6-8 hours |
| Light Source | 11PCS White LED + 2PCS Color LED |
| Lamp Luminous Flux(lm) | 500 |
| Lamp Luminous Efficiency(lm/w) | 160 |
| Color Temperature(CCT) | 6000K (Daylight) / 3500K (Warm White) |
| Beam Angle(°) | 120 |
| Color Rendering Index(Ra) | 80 |
| Material | ABS + PC |
| Input Voltage(V) | DC 6V |
| Support Dimmer | Yes |
| Lifespan (Hours) | 50000 |
| Working Temperature(℃) | -25 - 65 |
| IP Rating | IP65 (Water-Resistant) |
| Application | Outdoor Fence, Stair, Step, Garden, Front Door, Residential |
| Certification | RoHS, CE, FCC |
| Warranty | 1 Year |
| Control Method | Light Sensor + PIR Motion Sensor |
| Induction distance | 1.5 - 2 Meters (30 seconds PIR time) |
| Feature | Portable, Hanging, Wireless Control, Easy Installation |
| Place of Origin | Guangdong, China |
| Lighting solutions service | Garden, Front door, Wall, Residential, Fence lighting |
Stocked items: dispatched in 1–3 business days by tracked express courier – 5–10 business days Australia, 7–15 Europe/UK/US/Canada, 10–25 rest of world.
Project / quote-only items: air or sea freight, lead time stated in your quotation.
30-day change-of-mind returns. Faulty or damaged items replaced or refunded under the Australian Consumer Law.
Project Configuration Presentation for Flawless Installation:
We offer product lists and layout planning support for your projects.
100% SOLAR POWERED
Zero electricity bills and zero wiring. Harness the sun's energy for sustainable, high-performance lighting.
ALL-WEATHER DURABILITY
Engineered with premium IP-rated protection to withstand rain, snow, and extreme outdoor conditions year-round.
SMART ENERGY CONTROL
Advanced built-in sensors automatically manage brightness to maximize battery life and provide light exactly when needed.
EVIEKO TECHNICAL DATASHEET
Solar Motion Wall Light 300lm – PIR, 3 Lighting Modes
Overview
A compact round solar wall light with a tilted solar panel on top and a PIR motion sensor under the LED array. Choose dim-plus-motion, off-plus-motion or constant light; a 1200mAh battery gives 3–4 days of use after a full charge. Mount it on a wall, fence or post along paths, steps and entrances.
Available in 1, 4 and 8 packs — multi-packs cut the per-unit shipping cost.
Key features
- 300 lm LED array, 160 lm/W
- PIR motion sensor + light sensor – automatic at night
- Three lighting modes: 25% dim + motion, off + motion, constant
- Tilted high-efficiency solar panel
- Compact Ø112 × 46 mm black ABS + PC body, IP65
Specifications
| Solar panel power | 0.6W, 5V, high efficiency |
|---|---|
| LED | 300 lm, 160 lm/W, 6000–6500K, >50,000 h |
| Battery capacity | Li-ion 1200mAh |
| Charging time | 6–8 hours in bright sunshine |
| Lighting time | 3–4 days after full charge |
| Sensor | Light sensor + PIR motion sensor |
| Lighting modes | 1) 25% dim, 100% on motion 2) off, 100% on motion 3) constant light |
| Material | ABS + PC lens |
| Product size | Ø112 × 46 mm |
| IP rating | IP65 |
| Working temperature | -25°C to 60°C |
| Certificates | CE, RoHS, FCC; ISO 9001:2015 certified production |
| Warranty | 12 months |
Variants & SKUs
- Single
EV-WL-109 - 4-pack
EV-WL-109-4 - 8-pack
EV-WL-109-8
Packaging
Plain box 15 × 12 × 7.5 cm, 2 pcs per box, 0.28 kg. Master carton 36 × 46 × 46 cm, 54 boxes (108 pcs), 19 kg.
Ideal for
Houses, garages, driveways, gardens, patios, side and back yards, stairs, entrances, paths and fences.
Specifications per EVIEKO model EV-WL-109 technical data.
Warranty & compliance
Warranty period as stated in the specifications; faulty goods replaced or refunded under the Australian Consumer Law. CE / RoHS; IP rating per specifications. Certificates and photometric (IES) files for this model are supplied with project quotations or on request.
